      D3SL-T/RFID electromagnetic locking type

      ·Electromagnetic force locking 500N

      ·Adopt a small plane "electromagnetic" locking structure.

      ·Support 16 to 20 cascaded connections.

      ·Design of permanent magnet in matcher

      ·Small body, simple installation

      ·Full-angle eye-catching indicator light

      ·No abrasive powder will be produced.

      ·IP65/IP67 protection


      D3SL-T/RFID Series Selection Table

      Locking mode

      deploy

      model

      Output mode

      coded system

      Electromagnetic locking

      normalized form

      D3SL-T-DB-N2

      NPN

      universal coding

      D3SL-T-DB-N1

      NPN

      Unique coding

      D3SL-T-DB-P2

      PNP

      universal coding

      D3SL-T-DB-P1

      PNP

      Unique coding

      Advanced type

      D3SL-T-DG-N2

      NPN

      universal coding

      D3SL-T-DG-N1

      NPN

      Unique coding

      D3SL-T-DG-P2

      PNP

      universal coding

      D3SL-T-DG-P1

      PNP

      Unique coding


      Technical parameters of D3SL-T/RFID

      type

      Hinged door

      small-sized

      M12 connector

      normalized form

      High functional type

      working distance

      Sao(off-0n)

      4mm

      Sar(on-0ff)

      4mm

      Response time

      Lock → release

      155ms

      Release → lock

      155ms

      Detection → Non-detection

      20ms+2ms* (Number of cascaded connections -1)

      Non-detection → detection

      300ms+25ms* (Number of cascaded units -1)

      Control output

      (OSSD output)

      Output mode

      Transistor output "2

      Maximum load current

      150mA

      Residual voltage (on)

      Maximum ?2.5V (when the cable is 5m) and 3.5V (when the cable is 31m).

      OFF voltage

      Maximum ?2.0V (when the cable is 5m) and 3.0V (when the cable is 31m).

      leakage current

      Up to 0.5mA

      Maximum load capacity

      0.8uF

      Load connection resistance

      Max. 2.5 Euro

      AUX output

      (Non-safety system output)

      Output mode

      Transistor output

      Maximum load current

      50mA

      Residual voltage (ON)

      Maximum 2.5V (when the cable is 5m) and 3.5V (when the cable is 31m).

      external input

      (Short-circuit current)

      Safety input

      About 1.5 max 2

      Locking control input OSSD action switching input

      About 2.5 mA

      Reset /EDM input

      About 5mA (high functional type only)

      EDM select input

      About 2.5 mA (high functional type only)

      Power Supply

      Power supply voltage

      24 VDC 10% including ripple (P-P)10% Class2

      consumed power

      <5W

      protective circuit

      Reverse connection protection of power supply, short circuit protection of outputs, surge protection of outputs and reverse connection protection of outputs.

      Environmental resistance

      Enclosure protection grade

      IP65/67(IEC60529)

      Operating ambient temperature

      20 degrees below zero to 55 degrees without freezing.

      Storage ambient temperature

      25 degrees below zero to 70 degrees without freezing.

      Using ambient humidity

      5% to 95%RH

      Storage environment humidity

      5% to 95%RH

      Vibration resistance

      10 to 55 Hz, double amplitude 2.0 mm, X, Y and Z directions for 5 minutes (IEC60947-5-3

      Applicable standards

      ENISO13849-1:2015(PLe,Category4), IEC60947-5-3,EN60947-5-3


      Model description of safety switch




      hookup

      Standard type (NPN, cascade)

      Standard (PNP, cascade)


      Standard type (NPN, cascade)


      Standard (PNP, cascade)


      Functional (NPN, cascade)

      Functional (PNP, cascade)


      "Open and close linkage, purple is connected to 0V; Locking linkage purple disconnection

      "1. Use EDM and reset: wiring as shown in the figure.

      2. Do not use EDM and reset: connect EDM (pink line) and reset /EDM (light green) to +24V.

      3. Only use EDM: Turn off the EDM selection (pink line).

      K1.K2: External equipment (forced guided relay, electric and magnetic contactor, etc.)

      S: reset switch

      "Open and close linkage, purple is connected with +24V; Locking linkage purple disconnection

      "1. Use EDM and reset: wiring as shown in the figure.

      2. Do not use EDM and reset: connect EDM selection (pink line) and reset /EDM (light color recording) to 0V.

      3. Only use EDM: Turn off the EDM selection (pink line).

      K1.K2: External equipment (forced guided relay, electromagnetic contactor, etc.)

      S: reset switch

      High functional type (NPN, cascade)


      "Open and close linkage, purple is connected to 0V; Locking linkage purple disconnection

      1. Use EDM and reset: wiring as shown in the figure.

      2. Do not use EDM and reset: connect EDM (pink line) and reset /EDM (light green) to +24V;

      3. Only use EDM: Turn off the EDM selection (pink line).

      K1,K2: External equipment (forced guided relay, electromagnetic contactor, etc.)

      S: reset switch

      "Open and close linkage, purple is connected to 0V; Locking linkage purple disconnection

      1. Use EDM and reset: wiring as shown in the figure.

      2. Do not reset EDM: Select EDM (chalk line) and reset /EDM (light green) to+24V;

      3. EDM only: Turn off the EDM selection (chalk line).

      K1,K2: External equipment (forced guided relay, electromagnetic contactor, etc.)

      S: reset switch

      Functional (PNP, cascade)


      Open and close linkage, purple connected to +24V; Locking linkage purple disconnection

      1. Use EDM and reset: wiring as shown in the figure.

      2. Do not use EDM and reset: connect EDM (pink line) and reset /EDM (light green) to OV;

      3. Only use EDM: Turn off the EDM selection (pink line).

      K1,K2: External equipment (forced-guided dimensional appliances, electromagnetic contactors, etc.)

      S: reset switch

      Open and close linkage, purple connected to +24V; Locking linkage purple disconnection

      *1. Make ?EDM and reset: wire as shown in the figure.

      2. Do not reset EDM: Select EDM (chalk line) and connect reset /EDM (light green) to 0V;

      3. EDM only: Turn off the EDM selection (chalk line).

      K1,K2: External equipment (forced guided relay, electromagnetic contactor, etc.)

      S: reset switch
