      LC4 cascade safety grating


      ·Security level reaches Type 4, PLe.
      ·The protection height is 140mm to 1420mm.
      ·A protection system consisting of a set of main gratings and 1 ~ 3 sets of auxiliary gratings, transmission lines and accessories.
      ·Four sets of gratings can be connected in series, and the total number of beams can reach 288 at most.
      ·Can realize the "serial setting" with increased detection height
      ·Set ",L-shaped setting and U-shaped setting of multi-sided protection.
      ·Pass TUV safety certification

      ▊Directives and standards
      EU directive
      Machinery Safety Directive 2006/42/EC and EMC Directive 2014/30/EUU
      European Standards
      EN 61496-1、EN 61496-2、EN 13849-1、EN 61326-1
      international standard
      IEC 61496-1、IEC 61496-2、ISO 13849-1、IEC 61326-1、ISO 13855
      national standard
      GB/T 19436.1、GB/T 19436.2、GB 4584

      ▊specifications and models
      Main optical grating
      serial number
      model
      Optical axis spacing
      Detection accuracy
      Detection distance
      Grating type
      7
      LC4-10-0480mm-Z
      10
      15
      0-6m
      Main grating
      8
      LC4-10-0520mm-Z
      10
      15
      0-6m
      Main grating
      9
      LC4-10-0560mm-Z
      10
      15
      0-6m
      Main grating
      10
      LC4-10-0600mm-Z
      10
      15
      0-6m
      Main grating
      11
      LC4-10-0640mm-Z
      10
      15
      0-6m
      Main grating
      12
      LC4-10-0680mm-Z
      10
      15
      0-6m
      Main grating
      13
      LC4-10-0720mm-Z
      10
      15
      0-6m
      Main grating
      14
      LC4-10-0760mm-Z
      10
      15
      0-6m
      Main grating
      15
      LC4-10-0800mm-Z
      10
      15
      0-6m
      Main grating
      16
      LC4-20-0240mm-Z
      20
      26
      0-6m
      Main grating
      17
      LC4-20-0280mm-Z
      20
      26
      0-6m
      Main grating
      18
      LC4-20-0320mm-Z
      20
      26
      0-6m
      Main grating
      19
      LC4-20-0360mm-Z
      20
      26
      0-6m
      Main grating
      20
      LC4-20-0400mm-Z
      20
      26
      0-6m
      Main grating
      21
      LC4-20-0440mm-Z
      20
      26
      0-6m
      Main grating
      22
      LC4-20-0480mm-Z
      20
      26
      0-6m
      Main grating
      23
      LC4-20-0520mm-Z
      20
      26
      0-6m
      Main grating
      24
      LC4-20-0560mm-Z
      20
      26
      0-6m
      Main grating
      25
      LC4-20-0600mm-Z
      20
      26
      0-6m
      Main grating
      26
      LC4-20-0640mm-Z
      20
      26
      0-6m
      Main grating
      27
      LC4-20-0680mm-Z
      20
      26
      0-6m
      Main grating
      28
      LC4-20-0720mm-Z
      20
      26
      0-6m
      Main grating
      29
      LC4-20-0760mm-Z
      20
      26
      0-6m
      Main grating
      30
      LC4-20-0800mm-Z
      20
      26
      0-6m
      Main grating
      31
      LC4-20-0840mm-Z
      20
      26
      0-6m
      Main grating
      32
      LC4-20-0880mm-Z
      20
      26
      0-6m
      Main grating
      33
      LC4-20-0920mm-Z
      20
      26
      0-6m
      Main grating
      34
      LC4-20-0960mm-Z
      20
      26
      0-6m
      Main grating
      35
      LC4-20-1000mm-Z
      20
      26
      0-6m
      Main grating
      36
      LC4-20-1040mm-Z
      20
      26
      0-6m
      Main grating
      37
      LC4-20-1080mm-Z
      20
      26
      0-6m
      Main grating
      38
      LC4-20-1120mm-Z
      20
      26
      0-6m
      Main grating
      39
      LC4-20-1160mm-Z
      20
      26
      0-6m
      Main grating
      40
      LC4-20-1200mm-Z
      20
      26
      0-6m
      Main grating
      41
      LC4-20-1240mm-Z
      20
      26
      0-6m
      Main grating
      42
      LC4-20-1280mm-Z
      20
      26
      0-6m
      Main grating
      43
      LC4-20-1320mm-Z
      20
      26
      0-6m
      Main grating
      44
      LC4-20-1360mm-Z
      20
      26
      0-6m
      Main grating
      45
      LC4-20-1400mm-Z
      20
      26
      0-6m
      Main grating
      46
      LC4-20-1440mm-Z
      20
      26
      0-6m
      Main grating
      47
      LC4-20-1480mm-Z
      20
      26
      0-6m
      Main grating
      48
      LC4-20-1520mm-Z
      20
      26
      0-6m
      Main grating
      Sub-grating
      serial number
      model
      Optical axis spacing
      Detection accuracy
      Detection distance
      Grating type
      1
      LC4-10-0260mm-F
      10
      15
      0-6m
      Sub-grating
      2
      LC4-10-0300mm-F
      10
      15
      0-6m
      Sub-grating
      3
      LC4-10-0340mm-F
      10
      15
      0-6m
      Sub-grating
      4
      LC4-10-0380mm-F
      10
      15
      0-6m
      Sub-grating
      5
      LC4-10-0420mm-F
      10
      15
      0-6m
      Sub-grating
      6
      LC4-10-0460mm-F
      10
      15
      0-6m
      Sub-grating
      7
      LC4-10-0500mm-F
      10
      15
      0-6m
      Sub-grating
      8
      LC4-10-0540mm-F
      10
      15
      0-6m
      Sub-grating
      9
      LC4-10-0580mm-F
      10
      15
      0-6m
      Sub-grating
      10
      LC4-10-0620mm-F
      10
      15
      0-6m
      Sub-grating
      11
      LC4-10-0660mm-F
      10
      15
      0-6m
      Sub-grating
      12
      LC4-10-0700mm-F
      10
      15
      0-6m
      Sub-grating
      13
      LC4-10-0740mm-F
      10
      15
      0-6m
      Sub-grating
      14
      LC4-10-0780mm-F
      10
      15
      0-6m
      Sub-grating
      15
      LC4-10-0820mm-F
      10
      15
      0-6m
      Sub-grating
      16
      LC4-20-0250mm-F
      20
      26
      0-6m
      Sub-grating
      17
      LC4-20-0290mm-F
      20
      26
      0-6m
      Sub-grating
      18
      LC4-20-0330mm-F
      20
      26
      0-6m
      Sub-grating
      19
      LC4-20-0370mm-F
      20
      26
      0-6m
      Sub-grating
      20
      LC4-20-0410mm-F
      20
      26
      0-6m
      Sub-grating
      21
      LC4-20-0450mm-F
      20
      26
      0-6m
      Sub-grating
      22
      LC4-20-0490mm-F
      20
      26
      0-6m
      Sub-grating
      23
      LC4-20-0530mm-F
      20
      26
      0-6m
      Sub-grating
      24
      LC4-20-0570mm-F
      20
      26
      0-6m
      Sub-grating
      25
      LC4-20-0610mm-F
      20
      26
      0-6m
      Sub-grating
      26
      LC4-20-0650mm-F
      20
      26
      0-6m
      Sub-grating
      27
      LC4-20-0690mm-F
      20
      26
      0-6m
      Sub-grating
      28
      LC4-20-0730mm-F
      20
      26
      0-6m
      Sub-grating
      29
      LC4-20-0770mm-F
      20
      26
      0-6m
      Sub-grating
      30
      LC4-20-0810mm-F
      20
      26
      0-6m
      Sub-grating
      31
      LC4-20-0850mm-F
      20
      26
      0-6m
      Sub-grating
      32
      LC4-20-0890mm-F
      20
      26
      0-6m
      Sub-grating
      33
      LC4-20-0930mm-F
      20
      26
      0-6m
      Sub-grating
      34
      LC4-20-0970mm-F
      20
      26
      0-6m
      Sub-grating
      35
      LC4-20-1010mm-F
      20
      26
      0-6m
      Sub-grating
      36
      LC4-20-1050mm-F
      20
      26
      0-6m
      Sub-grating
      37
      LC4-20-1090mm-F
      20
      26
      0-6m
      Sub-grating
      38
      LC4-20-1130mm-F
      20
      26
      0-6m
      Sub-grating
      39
      LC4-20-1170mm-F
      20
      26
      0-6m
      Sub-grating
      40
      LC4-20-1210mm-F
      20
      26
      0-6m
      Sub-grating
      41
      LC4-20-1250mm-F
      20
      26
      0-6m
      Sub-grating
      42
      LC4-20-1290mm-F
      20
      26
      0-6m
      Sub-grating
      43
      LC4-20-1330mm-F
      20
      26
      0-6m
      Sub-grating
      44
      LC4-20-1370mm-F
      20
      26
      0-6m
      Sub-grating
      45
      LC4-20-1410mm-F
      20
      26
      0-6m
      Sub-grating
      46
      LC4-20-1450mm-F
      20
      26
      0-6m
      Sub-grating
      47
      LC4-20-1490mm-F
      20
      26
      0-6m
      Sub-grating
      48
      LC4-20-1530mm-F
      20
      26
      0-6m
      Sub-grating
